2.0 ton semi-electric pallet stacker, the model is BDD-A20 , the maximum loading capacity is 2000kg. The lifting height from 1600mm to 3500mm can be optional, also can customization according to the requirement of clients . The model has low voltage protection function, which can protect the battery under low voltage condition and prolong its service life
|
Model |
Unit |
BDD-A20 |
|
Driving mode |
|
Manual |
|
Rated load |
Kg |
2000 |
|
Load center distance |
mm |
500 |
|
Front overhang |
mm |
745 |
|
Wheel tread |
mm |
1185 |
|
Weight(with battery) |
Kg |
400 |
|
Wheel material |
|
Nylon wheel |
|
Front wheel size |
mm |
Φ180*50 |
|
Rear wheel size |
mm |
φ80*70 |
|
Lifting height of fork above ground |
mm |
1600/2000/2500/3000/3500 |
|
Height of the gantry is lowed |
mm |
2090/1590/1840/2090/2340 |
|
Maximum height of forklift work |
mm |
2100/2500/3000/3500/4000 |
|
Min. height of fork above ground |
mm |
90 |
|
Overall length |
mm |
1860 |
|
Fork size |
mm |
50*160*1100 |
|
Overall width |
mm |
800 |
|
Fork width |
mm |
320-1000 |
|
Radius of turning circle |
mm |
1425 |
|
Lifting speed, full load/no load |
m/s |
0.08/0.1 |
|
Falling speed, full load/no load |
m/s |
0.09/0.12 |
|
Service brake |
|
Mechanical brake |
|
Lifting motor power |
kw |
1.6 |
|
Battery |
V/Ah |
12/120 |
|
Noise level according to DIN12053 |
DB(A) |
<70 |
1. Q:Do you offer custom design?
2. Q:How about the sample policy?
A:We can accept sample order for testing quality, but sample and express charge should on customer’s account
3. Q:How about the delivery time?
A:Usually delivery time is 15-20 working days after we receive the advanced payment, for some standard products, we have most in stock and can delivery immediately
4. Q:May I visit your company?
A:We are always happy to serve you. our factory is located in Taizhou , Jiangsu province.there are international flights nearby and the traffic is well developed, if you would like to order our products and visit our company , pls contact us for an appointment
