hand pallet truck

Short Description:

Hand pallet Jack   ,manual pallet truck, manual pallet Jack

MOQ: 18pcs

FOB Price: $90-$140/pcs




Product Detail

Product Tags

Product advantage

1、        The pallet truck is economical in design;

2、        Standard epoxy resin powder coating, anti-fragmenta­tion, anti-corrosion;

3、        Extremely strong lightweight steel structure, the body weight is only 70kg;

4、        Solder joints and reinforced fork tips for durability;

5、        Three-stage handle - lifting, lowering, neutral;

6、        High quality 190 degree corner setting;

7、        The number of strokes of the oil pump is up to 8 times, and the height of each stroke is up to 11 mm;

8、        Reliable oil leakage hydraulic system;

9、        Optional:PU/Rubber load wheels,single wheel ,stainless steel and galvanized trucks available,various fork lengths and widths,backrests

Product parameter

Model

Unit

SDC-A2T

SDC-A2.5T

SDC-A3T

SDC-A5T

Rated load

Kg

2000

2500

3000

5000

Weight

Kg

60

65

70

132

Front wheel size

mm

φ180*50

φ180*50

φ180*50

φ180*50

Rear wheel size

mm

φ80*70

φ80*70

φ80*70

φ80*70

Lifting height

mm

200

200

200

200

Reduced height

mm

80

80

80

80

Fork length

mm

1150/1220

1150/1220

1150/1220

1150/1220

Fork outer width

mm

550/685

550/685

550/685

550/685

Wheelbase center to ground clearance

mm

30

30

30

30

Turning radius

mm

1265/1335

1265/1335

1265/1335

1265/1335

Suitable Pallet

fdsgfd
