The heavy forward full electric stacker has two model to choose, CQD-A15 and CQD-A20. The lifting height has large scale to choose, from 1600mm to 5000mm, the doorframe of this kind electric stacker can forward 500mm, can apply to all pallets.
1. The gantry column material is imported high-lift special steel;
2. The stacker has a compact structure, low center of gravity and good steering stability;
3. The fork has a front-rear tilt function, which is conducive to loading and unloading and stacking of goods;
4. Large capacity battery to ensure strong and lasting power;
5. The vehicle brake is reliable, combining electromagnetic braking with regenerative braking, which greatly extends the working life of the friction plate;
6. Reliable multi-way valve hydraulic control system has the functions of lifting, front-rear movement and front-rear tilt;
7. A rubber damping cushion is installed behind the doorframe to prevent the impact when the doorframe moves backwards and reduce noise;
|
Model |
Unit |
CQD-A15 |
CQD-A20 |
|
Drive mode |
|
Electric (battery) |
Electric (battery) |
|
Rated load |
Kg |
1500 |
2000 |
|
Load center distance |
C(mm) |
500 |
500 |
|
forward distance |
C(mm) |
500 |
500 |
|
Wheel tread |
Y(mm) |
1280 |
1280 |
|
Weight(with battery) |
Kg |
1800-2400 |
1800-2400 |
|
Wheel material |
|
PU |
PU |
|
Front wheel size |
(mm) |
φ250*80 |
φ250*80 |
|
Rear wheel size |
(mm) |
Φ210*85 |
Φ210*85 |
|
Number of wheels(X=driving wheel) |
|
1X/2 |
1X/2 |
|
Rear-wheel track |
B11(mm) |
895 |
895 |
|
Lifting height of fork above ground |
H3(mm) |
1600/2000/2500/3000/3500/4500/5000 |
1600/2000/2500/3000/3500 |
|
Height of the gantry is lowed |
H1(mm) |
2090/1590/1840/2090/2340/2090/2257 |
2090/1590/1840/2090/2340 |
|
Maximum height of forklift work |
H4(mm) |
2090/2590/3090/3590/4090/5090/5590 |
2090/2590/3090/3590/4090 |
|
Min. height of fork above ground |
H13(mm) |
50 |
50 |
|
Overall length |
L1(mm) |
2530 |
2530 |
|
Fork size |
s/e/l(mm) |
100*35*1070 |
100*35*1070 |
|
Overall width |
B1(mm) |
1000 |
1000 |
|
Fork width |
B5(mm) |
200-680 |
200-680 |
|
Channel width(1000*1200mm tray) |
Ast(mm) |
2600 |
2600 |
|
Channel width(800*1200mm tray) |
Ast(mm) |
2580 |
2580 |
|
Radius of turning circle |
Wa(mm) |
1600 |
1600 |
|
Driving speed, full load/no load |
Km/h |
4.5/5.2 |
4.5/5.2 |
|
Lifting speed, full load/no load |
m/s |
0.085/0.11 |
0.085/0.11 |
|
Falling speed, full load/no load |
m/s |
0.12/0.08(adjustable) |
0.12/0.08(adjustable) |
|
Service brake |
|
Electromagnetic brake |
Electromagnetic brake |
|
Driving motor power |
kw |
1.5 (AC) |
1.5 (AC) |
|
Lifting motor power |
kw |
2.2 (DC) |
2.2 (DC) |
|
Battery 24v |
Ah |
210 |
210 |
|
Battery weight |
kg |
210 |
210 |
|
Noise level according to DIN12053 |
DB(A) |
<70 |
<70 |
