1.0ton four wheel sit down type electric forklift
This mini sit down type four wheel electric forklift CPD10, the maximum loading capacity is 1000kg, the standard lifting height is 3000mm, easily operation, the power from battery, zero emission, no pollution.
1. Adopt imported motor to output strong traction and power so that it can still walk steadily on rough road and slope.
2. Adopt powerful hydraulic motor to supply more torque so as to make the truck lift and drop steadily.
3. More safe and confortable braking system.
4. Equipped with combined idler wheel with high strength and low deformation degree.
5. Equipped oil cylinder on the back to make a broaden sight.
6. Flow-limiting valve can adjust drop speed of portal frame. It can prevent portal frame from dropping fast even though the oil pipe explodes, and guarantee the safety of operator.
7. two-stage mast and double cylinder, ensure good operation version;
8. electronic power steering easier to control;
9. The whole car is simple to operate, convenient, large screen, LCD display
| 1.1 Model |
Unit |
CPD1030 |
| 1.2 Power |
|
battery |
| 1.3 Operator type |
|
sit down |
| 1.4 Loading capacity |
kg |
1000 |
| 1.5 Loading center distance |
mm |
450 |
| 1.6 Wheel base |
mm |
1100 |
| 1.7 Door frame dip angle(front/rear) |
° |
6°/12° |
| 1.8 Weight(include battery) |
kg |
1800 |
| 2.1 Tyre type |
|
solid tyre |
| 2.2 Front tyre |
mm |
18*6*12 1/8 |
| 2.3 Rear type |
mm |
15*5*11 1/4 |
| 2.4 Front wheel distance |
mm |
860 |
| 2.5 Rear wheel distance |
mm |
800 |
| 3.1 Overall length |
mm |
2635 |
| 3.2 Overall width |
mm |
1020 |
| 3.3 Overall height(the fork is lowest) |
mm |
2000 |
| 3.4 Overall height(the fork is highest) |
mm |
3800 |
| 3.5 Lifting height |
mm |
3000 |
| 3.6 Height of retaining frame |
mm |
1950 |
| 3.7 Front overhang |
mm |
370 |
| 3.8 Fork size |
mm |
100/35/920 |
| 3.9 Fork outer width(adjustable) |
mm |
200-1000 |
| 3.10 Min.ground clearance |
mm |
90 |
| 3.11 Channel width(1000*1200) |
mm |
3050 |
| 3.12 Turning radius |
mm |
1690 |
| 4.1 Driving speed full/empty |
km/h |
10/11 |
| 4.2 Lifting speed full/empty |
mm/s |
200/280 |
| 4.3 Max gradient with full load |
% |
15% |
| 5.1 Driving motor power |
kw |
4 |
| 5.2 Lifting motor power |
kw |
4 |
| 5.3 Battery capacity |
V/Ah |
48v/140ah |
| 5.4 use time |
h |
4.5 |
| 5.5 Control mode |
AC |
